Product Description:

  SG-RLL melt furnace, with reasonable structure, beautiful appearance, the furnace is all made of high purity aluminum fiber material built by unique numerical control process, strong heat and shock resistance, good corrosion resistance, no collapse, no crystallization, no slag, no pollution, long service life. The shell is made of cold rolled steel plate, processed by CNC machine tool, using high quality silicon molybdenum rod as heating element, and air cooling system. The furnace has the advantages of temperature field balance, low surface temperature, fast lifting temperature rate, energy saving and so on. The control system adopts microcomputer artificial intelligence adjustment technology, with PID adjustment, automatic control, self-setting function, multi-stage programming, and can compile various heating, insulation, cooling procedures, high temperature control accuracy; integrated module silicon control control and phase shift trigger. The degree of automation is relatively high, and all the indicators have reached the advanced level.

Main Uses And Scope Of Application:

  This equipment is widely used in universities, scientific research institutes, industrial and mining enterprises to do powder, electronics, metallurgy, medicine, ceramics, glass, machinery, new materials development, special materials, refractory materials, building materials, chemical industry, metal sintering and metal heat treatment and other experimental and production ideal equipment.

Main Functions And Characteristics:

1.The heating element adopts resistance wire / silicon carbon rod / silicon molybdenum rod, Choose the high-purity alumina fiber material for the furnace, Good thermal insulation performance, durable, High tensile strength, No miscellaneous ball, High in purity, Energy saving effect is better than domestic fiber materials;

2.Our software equipment through 485 or USB interface, It can realize the remote control, real-time tracking, history record, output report and other functions of a single or multiple electric furnace; paperless recording device can be installed, Realize data storage and output;

3.Over-temperature alarm and power off, earth leakage protection, Safe and reliable operation;

4.Furnace body: electrostatic spraying corrosion resistance and alkali resistance, The furnace wall temperature is close to room temperature;

5.Optional remote control touch screen operation mode, Fully functions: to control the temperature control system, Simple and easy to operate, and convenient Accurate and correct; AI adjustment algorithm, A set of measurement, show, control, report to the police, Intelligent touch screen with integrated functions such as recording, Can be realized for the temperature, pressure, Correct measurement and control of parameters such as flow and so on. With P2P cloud functionality (able to penetrate intranet monitoring without a public IP address), it allows for remote monitoring and operation via mobile devices such as smartphones and tablets.

　　6.Wide temperature control range, intelligent PID adjustment, microcomputer control, 30 programmable temperature control curve, no duty (automatic hotting, cooling, heat preservation).
