High temperature molten salt furnace realizes electrolytic reduction of oxides. (Stainless steel shell)
1) Suitable for small amount of molten salt stability test, simulating the actual working conditions of molten salt.
2) It has a series of advantages, such as anti-corrosion, high test accuracy, fast temperature rise and fall, low energy consumption and good stability.
3) High degree of automation of equipment.
Optional touch screen, real-time monitoring of temperature changes

Technical parameters:

Product model
SG-RYL900
Furnace size
250*250mm (depth*width*height)
Furnace material
High purity alumina
Outline size
According to actual manufacture
Working power supply
AC380V
Rated power
About 8KW
Common temperature
Less than 800 degrees centigrade
Maximum temperature
900 C
Recommended heating rate
1~15 C /min
temperature control
Intelligent PID control, micro-computer control, 30 programmable temperature control curve, without guard (automatic rise, fall, heat preservation)
control accuracy
+ 1 c
Weight
According to actual manufacture
Heating element
Resistance wire
Thermometric element
K-type thermocouple
Experimental Furnace of Shanghai Institute of Optical Precision Machinery, Chinese Academy of Sciences - Quality Advantage:
Senior Engineer, Master of Engineering and Doctor of Shanghai Institute of Optics and Precision Machinery, Chinese Academy of Sciences, can provide high temperature furnace design scheme for your company and research institute.
