System characteristics:
The lifting speed and rotating speed are set on the touch screen. They have fault alarm, alarm record, data record, automatic processing of power failure, overvoltage alarm, etc. The data record can be copied out by U disk and put into the computer for analysis.
The weighing system is suitable for small crystals. At present, many kinds of crystals have been grown successfully.
The technical parameters are as follows:
Tira:
Trip
400mm
Crystal velocity
0.1-15mm/h
fast
50-150 mm/min
Rotating speed
1-30r/min
Furnace body
Internal diameter 400 mm, height 700 mm
medium frequency power
25 kW
frequency
2.5-8KHz (optional)
power factor
> 0.9
efficiency
> 90%
Power Stabilization Accuracy
<0.5%
Rotary vane mechanical pump
TRP24
Diffusion pump
JK-150B
vacuum
Less than 10Pa (Limit Pressure 2x10-2Pa for Opening Diffusion Pump Cooling Furnace)
Weighing range
1 kg
Resolving power
0.05g
Flowing Gas in Furnace
0-500sccm, 0-10SLM (gas distribution mass flowmeter can choose one, two or more routes, range is optional)
Quality Advantages of Experimental Furnace of Shanghai Institute of Optical Precision Machinery, Chinese Academy of Sciences:
Senior engineer, master of engineering and doctor of Shanghai Institute of Optics and Precision Machinery, Chinese Academy of Sciences, can provide high temperature furnace design scheme for your company and research institute.
