Artificial intelligent thermostat / regulator
It supports a variety of thermocouple, thermal resistance, voltage, current, resistance andlinear radiation (IR) thermometer, and with the expansion of the special input specificationsinstalled input socket, 0.25 level of measurement accuracy, temperature drift is less than 100PPm/ DEG C.
The module output support SSR voltage, linear current (voltage), relay contact switch,thyristor contactless switch, single-phase, three-phase thyristor zero trigger, single phasesilicon controlled phase shifting triggering output.
The standard PID, AI artificial intelligence APID regulation and other regulation, self tuning,self-learning function, excellent control performance without overshoot and undershoot, can also use the position control (ON-OFF) function, two independent parameter PID can support the heating / cooling dual output function.
The AIBUS/MODBUS dual protocol: support RS485 or RS232C communication interface,convenient construction, small computer control system.
The upper limit, lower limit of support, deviation and deviation variety of lower limit alarm function, and can be freely defined 4 alarm output port, support for multiple alarm signal output from the same position. With the power from the alarm and other functions, to avoid the telegraph alarm malfunction.
- can view and modify parameters defining permissions, and allows the user to customizethe password, the most in line with their own customized operating habits of instrument.
The 30 section of the program control function, can realize arbitrary slope of the rise,temperature control, with the jump (cycle), pause and stop running, such as programmable/ operation command, and allows to modify the program in the control of the running program; the function of curve fitting with AI artificial intelligence control algorithm, can achieve smooth a smooth curve control effect; send output function by SV can be used as a generator; has measured start function, preparation and five kinds of power on / off event processing mode selection.
Panel size can be selected: A, A2, B, B2, C, C3, E, E2, E5, F, D, D2, D6
