Product Introduction:
　　The atmosphere furnace of ventilated sintering furnace uses silicon carbon rod as heating element, adopts double shell structure and intelligent temperature control system, and is triggered by phase shift and controlled by silicon control. The inner liner is made of temperature-resistant and pressure-resistant alloy material; The furnace door is equipped with circulating water cooling to ensure the reliable sealing of the furnace door and furnace gall.
Main Uses And Application Scope:
　　It is applied to the vacuum atmosphere treatment of electronic components, new materials and powder materials.
Main Functions And Features:
　　1.The inner liner is made of temperature and pressure resistant alloy material, can be vacuumed, the vacuum degree can reach -0.1MPa below, and can enter a variety of protective atmosphere;
　　2.The furnace adopts alumina poly-crystalline fiber material, good insulation performance, durable, high tensile strength, no stray ball, high purity, energy saving effect is better than domestic fiber materials, heating elements using high quality silicon carbon rod;
　　3.Through our software, and computer interconnection, can achieve a single or multiple electric furnace remote control, real-time tracking, history, output reports and other functions; Paperless recording device can be installed to realize data storage and output;
　　4.Over-pressure automatic pressure relief, over-temperature alarm and power off, leakage protection, safe and reliable operation;
